·Full color LCD
·Touch screen & vivid display
·Automatic color-choosing and selecting any kind of head you like to quilt and embroider.
·Imported linear guide rail, light-weighted saddletree system, ensure quilting mark are even, natural and nice
·Y direction unlimited embroidering, import tension motor ensure upper & lower fabric goes smoothly and simultaneously with the cotton
Two servo motor offer power to X/Y-axis, to sure machine working high speed and move precision.
Adopt 3.5 floppy disk and USB can be used with common embroidery machine.
Features of rolling design in Y direction, continuous embroidery &quilting on the cloth.
| Model | CM25-3 | CM33-3 | CM25-2 | CM33-2 | |
| Head | 25 | 33 | 25 | 33 | |
| Needle Distance | 135mm | 101mm | 67.5mm | 50.8mm | |
| Width | 3352.8mm | 3352.8mm | 3375mm | 3375mm | |
| Speed | 20-60m/h | 20-60m/h | 20-80m/h | 20-80m/h | |
| Size | L | 5000mm | 5000mm | 5300mm | 5300mm |
| W | 1100mm | ||||
| H | 1950mm | ||||
| Main Motor | Slip Motor | Servo Motor | |||
| Rotary Hook | Imported Normal Rotary Hook | Imported Normal Big Hook | |||
| Speed | (Max)750/RPM | (Max)1000/RPM | |||
| Colour | 3 | 2 | |||
| Needle Stitch | 0.15-12.7mm | ||||
| Needle Store | 120 million | ||||
| Pattern | 100 | ||||
| Power | 4.5-5Kw | ||||
| Weight | 2.5T | 2.6T | 2.7T | 2.8T | |
